Available Now! FRN003F1S-4U
Available Now! (1 in stock)

FRN003F1S-4U

Alt: FRENIC-Eco Series

$619.99

VFD, 3hp, 460V, 3 Phase, Variable Torque, Fan and Pump Drive

Weight:
9.86 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
In 1976, Fuji was the first in the industry to develop general purpose inverters! They helped expand in a number of fields based on their energy saving capabilities.

Today we are an authorized distributor for Fuji variable frequency drives, temperature controllers and HMI. Their FRENIC- line of VFDs are known for their high quality and the ability to suit a wide variety of application needs.
Specifications
Horsepower 3 hp
Housing/Enclosure IP20
Input Phase 3 Phase
Input Voltage 400-480V, 3 Phase
Outdoor Rated No
Output 3 Phase Output
Series FRENIC-Eco
Options Enclosed
STO (Safe Torque Off) No
Torque Load Constant/Variable (CT/VT)
Drives - Type of Drive Fan and Pump/HVAC
Warranty 3 Years
Quantity 1
Alternate Part Number FRENIC-Eco Series
Weight 9.855

Product Features Include:

Input Ratings:

  • Input Main Power Supply: 3 Phase, 380-480V, 50/60Hz
  • Input Auxiliary Control Power Input: Single-Phase, 380 to 480V, 50/60Hz
  • Voltage/Frequency Variations: Voltage: +10 to -15% (Voltage unbalance 2% or less) *9, Frequency: +5 to -5%
  • Rated Input Current (A): With DCR: 3.8, Without DCR: 6.9
  • Required Power Supply Capacity (kVA): 3.1

Output Ratings:

  • Rated Output Capacity (kVA): 4.3
  • Rated Voltage: 3 Phase, 380-480V (with AVR function)
  • Rated Output Current (A): 5.5
  • Overload Capability: 120% of rated current for 1 minute

General Specifications:

  • Torque (%): 20.0
  • DC Injection Braking: Starting Frequency: 0.0 to 60.0Hz, Braking Time: 0.0 to 30.0s, Braking Level: 0 to 60%
  • Enclosure: IP20, UL open type
  • Cooling Method: Fan Cooling
