Takex
F2RPN-J
Fiber Optic Sensor, Through Beam, PNP, Red LED, Requires Cable with Connector, 12/24VDC
$78.63
**Tariff Update: Select Manufacturer Tariffs Will Begin on April 14th, 2025** Read the latest!
F2RPN
$78.63
Fiber Optic Sensor, Through Beam, PNP, Red LED, Fiber Optic Cable, 12/24VDC, IP65
- Weight:
- 0.10 LBS
- Minimum Purchase:
- 1 unit
Description
Fiber Optic Sensor, Through Beam, PNP, Red LED, Fiber Optic Cable, 12/24VDC, IP65
Specifications
Connection
w/Cable
Light Source
LED
NPN or PNP
PNP (Source)
Sensing Method
Through Beam
Type of Photoelectric
Fiber Optic
All - Specific Ratings
IP65
Series
See Specs
Size
See Spec
Warranty
1 Year
Weight
.1
Features Include:
- Amazingly slim (8 x 10 x 73 mm)
- Amplifier can be used as if it were cable
- 2 output types: NPN or PNP
- Detection Method: Through beam type, reflective type (Dependent on fiber optic cable)
- Detecting Distance: Dependent on fiber optic cable
- Power Supply: 12 - 24V DC ±10% / Ripple 10% or less
- Current Consumption: 30mA or less
- Output Mode: PNP Open Collector Output Rating: Sink current 100mA (30VDC) or less
- Operation Mode: Light ON/Dark ON selector switch/timer selector switch provided
- Response Time: 500μs or less
- Hysteresis: Up to 10% of detecting distance
- Light Source: Infrared LED (660nm)
- Volume (VR): SENS : Sensitivity adjustment volume provided
- Switch (SW): Light ON/Dark ON selector switch/timer selector switch provided
- Material: Case: Noryl (filler: styrene elastomer)
- Connection: Attached cable (outer dimension: dia. 3.5) 0.2sq. 3 cores, 2m
Indicator:
- Red LED: Operation Indicator
- Green LED: Stability Indicator
Environmental Specifications:
- Ambient Light: 3,000 lx or less
- Ambient Temperature: -25 - +55 °C, Storage: -40°+70° (non-freezing)
- Ambient Humidity: 35 - 85%RH (non-condensing)
- Vibration: 10 - 55 Hz / 1.5 mm double amplitude / 2 hours each in 3 direction
