055427

Euchner is a leading global manufacturer of a complete line of safety solutions. Their products include a full line of safety switches; limit, interlock, foot, rope pull and emergency stop. They also offer safety controllers, light curtains, multifunctional gate boxes and ID systems.



Founded by Emil Euchner in 1940, Euchner remains a family owned company.

Series Features Include:

• 3-stage function
• Housing G2
• Straight connecting cable, 5 m
• Including holder
• Housing: Cap Elastomer, low PAH, black, Housing Plastic, yellow
• Connecting Cable: 6x0.34 mm²
• Connection: flying lead
• Degree of protection: IP65
• Rated Conditional Short-Circuit Current: 100 A
• Rated Impulse Withstand Voltage Uimp: 2.5 kV
• Rated Insulation Voltage Ui: 250 V
• Switching Current (min. at 24 V): 1 mA
• Switching Voltage (min. at 10 mA): 12 V
• Utilization category: AC-15 2A 230V, DC-13 2A 24V
• Number of NO contacts 2
• Number of positively driven contacts 1
• Switching principle: Slow-action contact elements

Technical Information:

• Euchner ZS Series Enabling Switches Catalog
• Euchner ZSA/ZSR Series Enabling Switches Instruction Guide
