Available Now! 80321S3012
Available Now! (1 in stock)

80321S3012

Alt: N321S NTC

$69.00

DIfferential Temperature Controller, 2 NTC-Type Sensors, One Output, 100-240VAC/VDC or 12-30VAC/DC, for Solar Heating Applications, Control Relay Output Switches the Water Circulation Pump, Protection Against Pipeline Freeing or Overheating

Weight:
0.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description

Our Novus N321 temperature controllers are available in four different sensor inputs; Pt100, Pt1000, thermocouple J or thermister (please see spec sheet or individual part numbers for sensor input).

These temperature controllers are used to measure, indicator and control temperature in a wide range of applications!

The front is IP65 and the output is relay, SPDT.



Features Include:

  • NTC Thermistor: 10 kΩ @ 25 °C, range: -30 to +105°C (-22 to 221 °F), Accuracy: 0.6 °C (1.1 ºF)
  • Sensor interchangeability: 0.75 ºC (1.35 ºF)
  • Measurement Resolution: 0.1º from –19.9 to 119.9º
  • Output: Relay SPDT, 1 HP 250 VAC / 1/3 HP 125 VAC (16 A Resistive)
  • Power Supply: 100 to 240 VAC/DC ±10%
  • Optionally: 12 to 30 VDC/AC
  • Power Consumption: 5 VA
  • Mains Frequency: 50~60 Hz
  • Dimensions: 75 x 33 x 75 mm
  • Panel: 70 x 29 mm
