DIB02CB23150MV
Alt: Minimum Order 5 Pieces, Price per Piece, *Includes Tariff
$148.40
Monitoring Relay, 115-230VAC, SPDT, 6 to 150mV AC/DC and 0.4 to 4 Vp AC (MI or MP Range), Single Phase, DIN Rail Mount, This Item Includes a Tariff That The Manufacturer Has Added
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 5 units
Description
Our Carlo Gavazzi DIB02 series are precise TRMS AC/DC over or under current monitoring relays.
The DIB02 is a DIN rail mount, SPDT monitoring relay.
Specifications
Alternate Part Number
Minimum Order 5 Pieces, Price per Piece, *Includes Tariff
Amp Rating
See Spec
Monitoring Relay Type
Current
Phase
Single Phase
Poles
SPDT
All - Voltage
120/240VAC
Warranty
1 Year
Weight
1
Features Include:
- TRMS AC/DC over or under current monitoring relays
- Current measuring through external shunt or CT
- Selection of measuring range by DIP-switches
- Measuring ranges from 6 to 150 mV AC/DC and 0.4 to 4 Vp AC (MI or MP range)
- Adjustable current on relative scale
- Adjustable hysteresis on relative scale
- Adjustable delay function (0.1 to 30 s)
- Programmable latching or inhibit at set level
- Output: 8 A SPDT relay N.D. or N.E. selectable
- For mounting on DIN-rail in accordance with DIN/EN 50 022 (DIB02) or plug-in module (PIB02)
- 22.5 mm Euronorm housing (DIB02) or 36 mm plug-in module (PIB02)
- LED indication for relay, alarm and power supply ON
- Galvanically separated power supply
