0627043463
Alt: 627043463, BK63H 2P D4A 6kA 480Y/277VAC UL1077
$16.50
MCB, UL1077, 2-Pole, D-Curve, 4 Amp, 6kA, 480Y/277VAC, Thermal Magnetic Miniature Circuit Breaker
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Choose Your Motor Starter Solution
Build your motor starter system with knowledgeable guidance on selecting your components, including starters, contactors, relays, and accessories.
Description
LS Electric is a global manufacturer of electrical power distribution equipment that includes circuit breakers and motor starters as well as variable frequency drives and HMIs.
LS Electric America, formerly LG Industrial Systems and LSIS, is a subsidiary of LS Electric headquartered in South Korea.
Specifications
Alternate Part Number
627043463, BK63H 2P D4A 6kA 480Y/277VAC UL1077
Amp Rating
4 Amp
Circuit Breaker Type
UL1077
Poles
2 Pole
Series
BK Series
Short Circuit Capacity
6kA
Trip Curve
D Curve
All - Voltage
480Y/277VAC
Warranty
2-1/2 Years
Weight
1
Features Include:
- Rated Frequency: 50/60 Hz
- Reference Temperature: 40°C
- Trip Type: Thermal Magnetic
- Type of Terminals: Terminal with stirrup(Indirect pressure)
- Tightening Torque: 2Nm (17.5 lbf-in)
- Installation: Mounting on 35mm din rail
