3D25UL
$76.91
Circuit Breaker, 3-Pole, D-Curve, 25 Amp, UL48910kA, Branch Circuit Protection, 480Y/277VAC
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
These UL Series circuit breakers are manufactured by ABL Sursum for Altech.
These UL489 miniature molded case circuit breakers are available in AC (UL suffix) or DC (DL suffix) models.
These circuit breakers are DIN rail mounted, 17.5mm width and have 10kA short capacity.
Marshall Wolf Automation is your authorized Altech distributor!
Specifications
Amp Rating
25 Amp
Circuit Breaker Type
UL489
Poles
3 Pole
Series
UL Series (D-trip)
Short Circuit Capacity
10kA
Trip Curve
D Curve
All - Voltage
480Y/277VAC
Warranty
1 Year
Weight
1
Series Features Include:
- AC Current/Voltage Rating: 0.3 - 63A/ 240V AC, 0.3-32A/ 480Y/277V AC*
- DC Current/Voltage Rating: 0.3 - 63A/ 250V DC
- Terminal Torque: 2 Nm (17.7 lb.in.) / 2.5Nm (22.2 lb.in)
- Available in AC and DC models
- DIN Rail Mounted
- 17.5mm width
- Thermal Magnetic
- Current Limiting (UL tested)
- 10kA Short Circuit Interrupting Capacity
- HACR Type 40°C
- Line/Load reversible
