2D20UL
$51.28
Circuit Breaker, 2-Pole, D-Curve, 20 Amp, UL489, 10kA, Branch Circuit Protection, Molded Case
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
When you need branch circuit protection, we offer a UL489 Miniature Molded Case Circuit Breakers in both AC and DC voltages. The AC version offers dual voltage rated circuit breakers at 0.2-63A/240VAC and 0.2-32A/480Y/277VAC in 1-3 poles. The DC version offers 0.2-63A at 125V (1 pole) and 250V (2 pole).
Molded case circuit breakers (also called MCCB's) automatically interrupt the current flowing through it when the current exceeds the trip rating of the breaker.
Specifications
Amp Rating
20 Amp
Circuit Breaker Type
UL489
Poles
2 Pole
Series
UL Series (D-Trip)
Short Circuit Capacity
10kA
Trip Curve
D Curve
All - Voltage
480Y/277VAC
Warranty
1 Year
Weight
1
Series Features Include:
- AC Current/Voltage Rating: 0.3 - 63A/ 240V AC, 0.3-32A/ 480Y/277V AC*
- DC Current/Voltage Rating: 0.3 - 63A/ 250V DC
- Terminal Torque: 2 Nm (17.7 lb.in.) / 2.5Nm (22.2 lb.in)
- Available in AC and DC models
- DIN Rail Mounted
- 17.5mm width
- Thermal Magnetic
- Current Limiting (UL tested)
- 10kA Short Circuit Interrupting Capacity
- HACR Type 40°C
- Line/Load reversible
