$16.21
**Tariff Update: Select Manufacturer Tariffs Will Begin on April 14th, 2025** Read the latest!
Available Now!
Available Now!
(26 in stock)
0626031863
Alt: 626031863, BK63H 1P C2A 10kA 120/240VAC UL1077
$7.71
MCB, UL1077, 1-Pole, C-Curve, 2 Amp, 10kA, 120/240VAC, Thermal Magnetic Miniature Circuit Breaker,
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Easily Find Your Enclosure Solution
Get expert guidance to select the right enclosure and compatible accessories, including subpanels, fans, filters, heaters, thermostats, air conditioning units, and heat exchangers.
Description
LSIS (formerly LG Industrial Solutions) offers miniature circuit breakers in both UL1077 and UL489.
UL1077 miniature circuit breakers (BK63H) are suitable for overload and short circuit protection while UL489 miniature circuit breakers (BK63HU) are used for branch circuit protection.
The BK63H series (UL1077) and the BK63HU series (UL489) are both available in 1, 2, 3 or 4 poles, in B, C or D trip curves and from 1 to 63 amp.
Marshall Wolf Automation is your authorized stocking LSIS distributor.
Specifications
Alternate Part Number
626031863, BK63H 1P C2A 10kA 120/240VAC UL1077
Amp Rating
2 Amp
Circuit Breaker Type
UL1077
Poles
1 Pole
Series
BK Series
Short Circuit Capacity
10kA
Trip Curve
C Curve
All - Voltage
120/240VAC
Warranty
2-1/2 Years
Weight
0.5
Quantity
26
Features Include:
- Rated Frequency: 50/60 Hz
- Reference Temperature: 40°C
- Trip Type: Thermal Magnetic
- Type of Terminals: Terminal with stirrup(Indirect pressure)
- Tightening Torque: 2Nm (17.5 lbf-in)
- Installation: Mounting on 35mm din rail
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
$22.70
$26.77
$26.77
$26.77
$13.78
