Baumer
CFAM 30N1600/S14
Capacitive Proximity Sensor, Ø30mm Cyl., 15mm Range, Flush, NPN NO, M12, IP65
$347.74
CFAM 30N1600
Alt: 10119708, *Includes 6% Tariff from Manufacturer
$371.46
Capacitive Proximity Sensor, Ø30mm Cyl., 15mm Range, NPN NO, 2m Cable, IP65
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Specifications
Alternate Part Number
10119708, *Includes 6% Tariff from Manufacturer
Connection
w/Cable
Material
Nickel Plated Brass
Normally Open/Closed
Normally Open (NO)
NPN or PNP
NPN (Sink)
All - Specific Ratings
IP65
Series
CFAM Series
Shielded/Unshielded
Shielded - Flush
Size
30mm
Type of Sensor
Capacitive
All - Voltage
10-30VDC
Warranty
3 Years
Weight
.5
Features Include:
- Nominal Sensing Distance Sn: 15 mm
- Nominal Sensing Distance Sn Adjustable: 4 - 15 mm
- Mounting Type: Flush
- GND Electrode: Yes
- Temperature Drift: ±15% (+10 - +70°C)
- Sensitivity Adjustment: Potentiometer, 18 turn
- Output Indicator: LED yellow
- Switching Frequency:< 50 kHz
- Voltage Supply Range +Vs: 10 - 30 VDC
- Current Consumption Max. (no load): 20 mA
- Voltage Drop: < 1.5 VDC
- Output Current: < 200 mA
- Housing Material: Nickel Plated Brass
