Baumer
CFAM 12N3600
Capacitive Proximity Sensor, Ø12mm Cyl., 4mm Range, Flush, NPN NC, 10-30VDC, 2m Cable, IP65
$386.20
**Tariff Update: Currently in 'Wait and See' Mode Instead of 'Panic and Overcharge' Mode!** Read the latest!
CFAM 12N3600/S14
Alt: 10119688
$358.24
Capacitive Proximity Sensor, Ø12mm Cyl., 4mm Range, Flush, NPN NC, 10-30VDC, M12, IP65
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Specifications
Alternate Part Number
10119688
Connection
M12, Straight
Material
Nickel Plated Brass
Normally Open/Closed
Normally Closed (NC)
NPN or PNP
NPN (Sink)
All - Specific Ratings
IP65
Series
CFAM Series
Shielded/Unshielded
Shielded - Flush
Size
12mm
Type of Sensor
Capacitive
All - Voltage
10-30VDC
Warranty
3 Years
Weight
.5
Features Include:
- Nominal Sensing Distance Sn: 4 mm
- Nominal Sensing Distance Sn Adjustable: 0.5 - 4 mm
- Mounting Type: Flush
- GND Electrode: Yes
- Temperature Drift: ±15% (+10 - +70°C)
- Sensitivity Adjustment: Potentiometer, 240
- Output Indicator: LED yellow
- Switching Frequency:< 50 kHz
- Voltage Supply Range +Vs: 10 - 30 VDC
- Current Consumption Max. (no load): 20 mA
- Voltage Drop: < 1.5 VDC
- Output Current: < 200 mA
- Housing Material: Nickel Plated Brass
