Our Patlite LR series is available in four diameters; 40, 50, 60 or 70mm.
- LR4 Series - 40mm, 24VDC or 100-240vAC
- LR5 Series - 50mm, 12VDC or 24VDC
- Also available with manual control switch box (HSST-3M2)
- LR6 Series - 60mm, 24VDC or 100-240VAC
- Multi-color LED module available, 7 colors in one (LR6-E-MZ)
- Available with M12 connector, 1/2" NPT or 30mm through-hole mounting option
- LR7 Series - 70mm, 24VDC only
All LR light towers offer:
- Ultra-bright LEDs - brilliant, even light
- IP65 (IEC 60529), NEMA 4X, 13, indoor use
- Modular twist and lock design, easily customize and field configure LED units and sound modules
- Completely enclosed optional sound module maintains substantial water and dust protection, 360° sound!
- Sleek, smooth and rugged housing
- Four mounting options - direct, pole with L-bracket, pole with circular bracket, pole with folding pracket (off-white only)
- Available in off-white or silver bodies
- NPN/PNP transistor output (AC100-240V is NPN only)
- Operating ambient temperature -20°C to 50°C
- 2 year warranty
- The LR series replaced LCE-A, LCS-A, LE, LES, LU5, LME, LMS, LME and LU7 series
Patlite introduces their WD Wireless Data Series!
Modernize your workplace with Patlite's WD wireless data acquisition system - receive real time sttatus alerts straight from the factory floor to any computer!
The system consists of a Patlte light tower + transmitter (see below) which will send information to the receiver (WDR-LE-Z2-PRO):
- For the LR4 series - use wireless data transmitter WDT-4LR-Z2, will also need receiver WDR-LE-Z2-PRO
- For the LR5 series - use wireless data transmitter WDT-5LR-Z1, will also need receiver WDR-LE-Z2-PRO
- Two options for the LR6 series:
- use WDT-6LR-Z1, will also need receiver WDR-LE-Z2-PRO
- or use WDT-6LR-Z1-PRO - will also need receiver WDR-LE-Z2-PRO and WDB-D80S-PRO base
