Menics
MS70LT-MBFF-Y
Beacon, Ø70mm, LED, 110-220VAC, Yellow Lens, Direct Mount, Flashing & Buzzer, IP50
$98.91
MS70LT-MBFF-R
Alt: MS70LT Series
$98.91
Beacon, Ø70mm, LED, 110-220VAC, Red Lens, Direct Mount, Flashing & Buzzer, IP50
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Amerimation represents a number of top Korean brands that includes Menics light towers, Kacon and Boxco. They are the sole representative for North and South America.
Known for their competitive prices, Amerimation sells through distribution and is located right here in Illinois. Most products can ship from our stock, or theirs, within 1 to 2 days.
Specifications
Beacon Type
See Spec
Color
Red
Diameter
70mm
Light Tower Mounting
Direct/Surface Mount
All - Specific Ratings
IP50
Series
MS70LT Series
All - Voltage
120/240VAC
Warranty
3 Years
Alternate Part Number
MS70LT Series
Weight
0.5
Series Features Include:
- Function: Steady, Flashing, Buzzer
- Power Supply: 12 ~ 24VDC, 110 ~ 220VAC(AC 50/60Hz)
- Alarm Sound: min 50 ~ max 80±5dB
- Dimension: 68mm
- Flashing rate (2 patterns): Normal flashing : 75±5 time/minute, 3 pattern flashing (Emergency signal), 130±5 time/minute
- Connection: UL2464 / 18AWG, AWM, 2C, 300V
- Material Body: Body - ABS resin Lens - PC resin
- Ambient temperature: -20 to 50°C
- Storage ambient: temperature -20 to 70°C
- Ambient Humidity: 45~85% RH
- Insulation resistance: 500VAC 50 / 60Hz for 1 minute
- Vibration: 10 to 55Hz (cycle 1 minute) Amplitude 0.75mm, X, Y, Z 1 hour in each direction
- Approval: CE(DC products only), RoHS
- Protection structure: IP65 (IP50-Buzzer type)
- Weight (DC type): G type: app.196g M type: app.195g P type: app.198g
Current consumption:
- Flashing type: 12~24VDC: 0.12~0.16A, 110~220VAC:0.04~0.05A
- Flashing + Buzzer type: 12~24VDC:0.16~0.21A, 110~220VAC: 0.05~0.06A
Accessories
Available Now!
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Menics
MS70LT-MBFF-C
Beacon, Ø70mm, LED, 110-220VAC, Clear Lens, Direct Mount, Flashing & Buzzer, IP50
$98.91
Menics
MS70LT-MBFF-G
Beacon, Ø70mm, LED, 110-220VAC, Green Lens, Direct Mount, Flashing & Buzzer, IP50
$98.91
Menics
MS70LT-MBFF-B
Beacon, Ø70mm, LED, 110-220VAC, Blue Lens, Direct Mount, Flashing & Buzzer, IP50
$98.91
$87.65
$87.65
$68.29
Menics
MS70LT-GBFF-R
Beacon, Ø70mm, LED, 110-220VAC, Red Lens, Surface Mount, Flashing & Buzzer, IP50
$96.45
$70.72
