Available Now! 03210
Available Now! (1 in stock)

03210

Alt: 3210

$129.99

Analog Panel Meter, Wide-Vue, 3.5", 0-50AC, Model 1357, .001 Impedance

Weight:
0.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Analog Panel Meter, Wide-Vue, 3.5", 0-50AC, Model 1357, .001 Impedance

Features Include:

  • Accuracy: ±2% F.S. (Iron-Vane), ±3 F.S. (Rectified)
  • Tracking: ±3%
  • Shielding: Calibration is unaffected by magnetic panel mounting
  • Response Time: 1.5 seconds maximum
  • Overload (1 second): 10 times F.S.
  • Continuous: 1.5 times F. S.
  • Dial: Sharp clear scale. Each dial arc is calibrated to track the specific type of movement used
  • Resistance: ±15% of meter impedance
  • Operating Temperature: -4°F to +149°F (-20°C to +65°C)
  • Case: High density black plastic
  • Pointer: Model 1212: black lance; all other models: Spade with black matte finish

Repeatability:

  • 2%: AC Current, DC Process
  • 3%: AC Voltage, DC Voltage, Wattmeters
  • 0.5%: DC Current
