02520
Alt: 2520
$143.93
Analog Panel Meter, Wide-Vue, 2.5", 0-30DC Model 1227, .0017 Impedance
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Analog Panel Meter, Wide-Vue, 2.5", 0-30DC Model 1227, .0017 Impedance
Specifications
Alternate Part Number
2520
Amp Rating
See Spec
Analog/Digital
Analog
Meter Type
Panel Meter
Series
Wide-Vue Series
All - Voltage
See Spec or N/A
Warranty
1 Year
Weight
.5
Features Include:
- Accuracy: ±2% F.S. (Iron-Vane), ±3 F.S. (Rectified)
- Tracking: ±3%
- Shielding: Calibration is unaffected by magnetic panel mounting
- Response Time: 1.5 seconds maximum
- Overload (1 second): 10 times F.S.
- Continuous: 1.5 times F. S.
- Dial: Sharp clear scale. Each dial arc is calibrated to track the specific type of movement used
- Resistance: ±15% of meter impedance
- Operating Temperature: -4°F to +149°F (-20°C to +65°C)
- Case: High density black plastic
- Pointer: Model 1212: black lance; all other models: Spade with black matte finish
Repeatability:
- 2%: AC Current, DC Process
- 3%: AC Voltage, DC Voltage, Wattmeters
- 0.5%: DC Current
