TV3AAA005
$185.24
Analog Panel Meter, Tru-Vue, 3-1/2" Model 953, 0-5AC, .008 Impedance
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Analog Panel Meter, Tru-Vue, 3-1/2" Model 953, 0-5AC, .008 Impedance
Specifications
Amp Rating
See Spec
Analog/Digital
Analog
Meter Type
Panel Meter
Series
See Specs
All - Voltage
See Spec or N/A
Warranty
1 Year
Weight
.5
Features Include:
- Accuracy: ±2% F.S. (iron vane), ±% F.S. (rectifier)
- Shielding: Calibration is unaffected by stray magnetic field or panel mounting
- Response Time: 1.5 seconds maximum above 10mA
- Dial: Sharp clear scale. Each dial arc is calibrated to track the specific type of movement used.
- Operating Temperature: -4°F to +149°F (-20°C to +65°C)
- Case: Clear plastic
- Modern, clear acrylic case updates panel design
- Black knife-edge pointer for precision reading
