IR-AQ04-VI
Alt: iR Series
$145.95
Remote I/O, Analog Output Point: 4 (-10 - 10V,4-20mA Mode, 12-bit Resolution)
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
The iR series are remote I/O that are available as Fieldbus coupler, analog (iR-A),digital (iR-D) or temperature options..
Specifications
Communication Module Type
I/O Modules
Series
iR Series
Warranty
1 Year
Alternate Part Number
iR Series
Weight
0.5
Features Include:
- Input Power: -10V ~ 10V, -20mA ~ 20mA
- Output Range: -10V ~ 10V, -20mA ~ 20mA
- Current Consumption: 70mA @ 5VDC
- Isolation: 500 VDC (Analog/Digital)
- Data Format: 4 ~ 20mA, 0~3200
- Number of Analog Inputs: 0
- Number of Analog Outputs: 4
- Dimensions (WxHxD): 27 x 109 x 81 mm
- Mount: 35mm DIN rail mounting
- Vibration Endurance: Conforms to EN 60068-2-6 / EN 60068-2-27
- Storage Temperature: -20° ~ 70°C (-4° ~ 158°F)
- Operating Temperature: -20° ~ 50°C (-4° ~ 122°F)
