SCE-AC1870B460V
$2,257.30
Air Conditioner, 1870 BTU, Hr. 460 Volt, UL IS19
- Weight:
- 85.80 LBS
- Minimum Purchase:
- 1 unit
Description
Saginaw offers just about every type of enclosure; steel, stainless steel, non-metallic and custom! All NEMA ratings and styles are available as well as a complete line of accessories.
Saginaw enclosures have been designed and manufactured in Michigan since 1963.
Features Include:
- Rated Operating Voltage / Frequency: 400/460 V - 50/60 Hz 3~
- Rated Current @ 95°F/95°F: 1.2 A
- Starting Current: 5 A
- Max. Current: 1.6 A
- Power Consumption @ 95°F / 95°F: 440 kW
- Max. Power Consumption: 560 kW
- Cooling Capacity @ 95°F / 95°F/: 1870 BTU (548 Watts)
- Cooling Capacity @ 131°F / 131°F: 1877 BTU (550 Watts)
- Heating Capacity: 400 W
- Compressor: Reciprocating Compressor
- Refrigerant: R134a
- Refrigerant Charge: 5.29 oz
- Max. Pressure: 348 psig
- Operating Temperature Range: -4°F - 131°F
Housing Material:
- Mild Steel, Powder Coated
- SS: Stainless Steel AISI 304
- SS6: Stainless Steel AISI 316
