Advantech
ADAM-6024-D
Ethernet I/O Module, 12 Channel Isolated Universal I/O Module, ADAM-6000 Series
$600.00
ADAM-6066-D
Alt: ADAM 6000 Series
$284.00
Ethernet I/O Module, 6 Channel Power Relay Module, 6 Digital Output / 6 Digital Input, 120 x 70 x 30mm (HWD)
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Advantech was founded in 1983 by three ex-Hewlett Packard engineers and released the first industrial PC (IPC-600) in 1990.
Features Include:
- Input Voltage: 10~30 VDC
- Contact Rating (Resistive): 3 A @ 30 VDC, 5 A @ 250 VAC
- Relay Type: 1 x Form A
- Interface: Ethernet
- Isolation Voltage: 2,000 VDC
- Connectors: 1 x RJ45, 1 x 13-pin plug-in screw terminal, 1 x 9-pin plug-in screw terminal
- Protocol: Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP, ASCII command
- I/O:6ch relay/6ch digital input(counter)
- GCL to perform basic logic control rules
- Peer-to-Peer function to map I/O status
- Cloud access: Data update to Azure
- Built-in web server
- Watchdog timer to recover the system
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Advantech
ADAM-6052-D
16-Channel Source-Type Isolated Digital I/O Modbus TCP Module, 8 Digital Inputs/8 Digital Outputs
$265.00
Advantech
ADAM-6051-D
16-Channel Isolated DI/O with Counter Module, 12-Ch DI, 2-Ch DO, Ethernet-based smart I/O
$246.00
$431.60
$380.10
Advantech
ADAM-3956-BE
DIN Rail Wiring Board, LED Indicators, CB-26 Connector, for PCI-1240/1245/1245E/1245V/1245L/1265/1285/1285E Application, Dimensions: (WLH): 122 x 171 x 45mm (4.8 x 6.73 x 1.77")
$106.40
$97.00
$450.50
