ADAM-4118-C
Alt: ADAM 4000 Series
$358.10
Remote I/O Module, 8-Channel Thermocouple Input Module, ADAM-4100 Series
- Weight:
- 0.75 LBS
- Minimum Purchase:
- 1 unit
Description
Advantech was founded in 1983 by three ex-Hewlett Packard engineers and released the first industrial PC (IPC-600) in 1990.
Specifications
Communication Module Type
I/O Modules
Series
ADAM 4000 Series
Warranty
2 Years
Alternate Part Number
ADAM 4000 Series
Weight
0.75
Features Include:
- 8ch thermocouple(can be set to voltage or current)
- Channels: 8 differential and independent configuration channels
- Input Voltage: 10~48 VDC
- Input Range: ±15 mV, ±50 mV, ±100 mV, ±500 mV, ±1 V, ±2.5 V, 0~15 mV, 0~50 mV, 0~100 mV, 0~500 mV, 0~1 V, 0~2.5 V
- lnput Type: mA, mV, V, T/C: J, K, T, E, R, S, B, N type
- Resolution (Bits): 16-bit
- Sampling Rates(S/s): 100 S/s (sum)
- Interface: RS-485, Micro USB
- Isolation Voltage: 3,000 VDC
- Connectors: 2 x 10-pin plug-in screw terminal
- Protocol: ASCII command, Modbus/RTU
- Watchdog Timer: System (1.6 second) & Communication
Downloads
- Advantech ADAM-4118/4150/4168 Module Technical Data
- Advantech ADAM-4000 Series User Manual
- Advantech ADAM-4000 Series Access Port Instructions
- Advantech ADAM-4000 Series AIO Calibration Instructions
- Advantech ADAM-4000 Series Reconnection Instructions
- Advantech ADAM-4000 Series DO Voltage/Current Datasheet
- Advantech ADAM-4000 Series Tolerance Range Datasheet
