$358.10
ADAM-4051-C
Alt: ADAM 4000 Series
$178.50
I/O Module, 16-Channel Isolated Digital Input Module with LED and Modbus, ADAM-4000 Series
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Advantech was founded in 1983 by three ex-Hewlett Packard engineers and released the first industrial PC (IPC-600) in 1990.
Features Include:
- 16-ch Isolated Digital Input Module with Modbus
- Connectors: 2 x plug-in terminal blocks (#14 ~ 22 AWG)
- Power Input Unregulated: 10 ~ 30 VDC
- Power Consumption: 0.4 W @ 24 VDC
- Channels: 8 (6 fully independent isolated channels, 2 isolated channels with common ground)
- Isolation Voltage: 5,000 VRMS
- Input Resistance: 3 kΩ
- Protocols: Modbus RTU,ASCII
- Watchdog timer to recover the system
Input Voltage:
- Dry Contact
- Logic level 1: close to DGND
- Logic level 0: open
- Wet Contact
- Logic level 1: 10~50 VDC
- Logic level 0: 0~3 VDC
Technical Information:
- Advantech ADAM-4050/4051/4052 Digital Input Modules Technical Data
- Advantech ADAM-4000 Series User Manual
- Advantech ADAM-4000 Series Access Port Instructions
- Advantech ADAM-4000 Series AIO Calibration Instructions
- Advantech ADAM-4000 Series Reconnection Instructions
- Advantech ADAM-4000 Series DO Voltage/Current Datasheet
- Advantech ADAM-4000 Series Tolerance Range Datasheet
