ADAM-3016-AE

Features Include:

• Connectors: Screw terminal
• Enclosure: ABS
• Indicators: Power LED indicator
• Isolation: 1,000 VDC (Three-way)
• Power Consumption: ≤ 1.85 W (voltage output), ≤ 2.15 W (current output)
• Power Input: 24 VDC ±10%
• Accuracy: ±0.1% of full range
• Bandwidth: 2.4 kHz (typical)
• Isolation Mode Rejection: >100 dB @ 50 Hz/60 Hz
• Current Output Current: 0 ~ 20 mA
• Current load resistor: 0 ~ 500 Ω (Source)
• Input Range: ±10 mV, ±20 mV, ±30 mV, ±100 mV
• Output Ranges: ±5 V, ±10 V, 0~10 V
• 1000 VDC 3-way optical isolation
• Switch configurable mV or V input of full bridge
• Switch configurable voltage and current outputs

Technical Information:

• Advantech ADAM-3016 / ADAM-3017 Signal Conditioner Technical Data
• Advantech ADAM-3016 Strain Gauge Input Module User's Manual
