6490642046
Alt: 649.0642.046, MAK-4256-3
$136.86
Magnetic Switch Non-Contact, Part of Safety System Can Be Used with Safety Evaluation Unit (MUZ Series)
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Bernstein is a German manufacturer of industrial safety and enclosure technology and are well known for a wide range of sensors, switches, enclosures and operating terminals.
If you do not see the part number you are looking for, please Contact Us, we can find what you need!
Specifications
Alternate Part Number
649.0642.046, MAK-4256-3
Amp Rating
See Spec
Type of Product
See Spec
Warranty
1 Year
Weight
1
Series
MA-42 Series
Type of Safety Switch
Coded Magnet
Features Include:
- Assured Operating Distance: 4 mm
- Switching Element Function: 2 x N.C. for the safety circuit, 1 x N.O. for signalling purposes (PK/GY; not coded)
- Max. Voltage: 130 V DC
- Ambient Temperature (min/max): -25°C/+70°C
- Protection Class: IP67
- Enclosure: PA6, black; encapsulated reed contact
- Termination Type: Cable 6 x 0,25 mm² x 3 m 5 %; PVC - Outer jacket, grey
