6311201686
Alt: 631.1201.686, MAK-0112-F-2
$85.33
Magnetic Switch Non-Contact, Part of Safety System Can Be Used w/Safety Evaluation Unit (MUZ Series)
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Bernstein is a German manufacturer of industrial safety and enclosure technology and are well known for a wide range of sensors, switches, enclosures and operating terminals.
If you do not see the part number you are looking for, please Contact Us, we can find what you need!
Features Include:
- Assured Operating Distance: 10 mm
- Switching Element Function: N.O.
- Reed Contact Max. Switching Voltage: 1000 V AC/DC
- Reed Contact Max. Switching Current: 1 A
- Reed Contact Max. Switching Capacity: 100 VA
- Ambient Temperature (min/max): -5°C/+70°C
- Protection Class: IP67
- Enclosure: PA 6.6, black; encapsulated reed contact
- Termination Type: Cable 2 x AWG 26 x 2 m ± 5 %; PVC -outer jacket black
