6310311693
Alt: 631.0311.693, MAK-1113-D-1, Replacement for 6310311615 (631.0311.615, MAK-1113-1)
$59.69
Magnetic Switch Non-Contact, Part of Safety System Can Be Used with Safety Evaluation Unit (MUZ Series)
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Assured Operating Distance: 8 mm
- Switching Element Function: Switch Over
- Max. Switching Voltage: 130 V
- Switching Current (max.): 0.25 A
- Performance Class (diagram No.): 3 VA
- Ambient Temperature (min/max): -5°C/+70°C
- Protection Class: IP67
- Enclosure: PA 6.6; black encapsulated reed contact
- Termination Type: Cable 3 x 0,14 mm2; PVC -outer jacket black
