Product image is representative only, please verify specifications.
6108116038
Alt: 610.8116.038, C2-U1Z R FLACHST.
$97.81
Limit Switch, Enclosed, Plastic Body
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Rated insulation voltage Ui: 250 V AC
- Conv. thermal current Ithe: 10 A
- Rated operational voltage Ue: 240 V
- Utilization category: AC-15, Ue /Ie 240 V / 3 A
- Short-circuit protective device: Fuse 6 A gG
- Enclosure: PBT
- Actuator: Roller (St)
- Contact type: 1 NC, 1 NO (Zb)
- Mechanical life: 3 x 106 switching cycles
- Switching frequency: ≤ 100/min
- Assembly: 2 x M3
- Connection: 4 flat plug 6,3
- Miniature switch for safety applications
- Two-channel safety monitoring possible
- With captive snap-on cover
- Small hysteresis in snap action system
- Slow-action and snap-action contacts
- Versions: 1 NC / 1NO, 2 NC, 2 NO
- Type: Zb (galvanically isolated changeover contact)
Technical Information:
