Product image is representative only, please verify specifications.
6108101039
Alt: 610.8101.039, C2-U1Z FLACHST.
$106.60
Limit Switch, Enclosed, Plastic Body
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Bernstein is a German manufacturer of industrial safety and enclosure technology and are well known for a wide range of sensors, switches, enclosures and operating terminals.
If you do not see the part number you are looking for, please Contact Us, we can find what you need!
Features Include:
- Rated insulation voltage Ui: 250 V AC
- Conv. thermal current Ithe: 10 A
- Rated operational voltage Ue: 240 V
- Short-circuit protective device Fuse: 6 A gG
- Enclosure: PBT
- Actuator: Plunger (St)
- Contact type: 1 NC, 1 NO (Zb)
- Mechanical life: 3 x 106 switching cycles
- Switching frequency: ≤ 100/min
- Assembly: 2 x M3
- Connection: 4 flat plug 6,3
- Miniature switch for safety applications
- Two-channel safety monitoring possible
- With captive snap-on cover
- Small hysteresis in snap action system
- Slow-action and snap-action contacts
- Versions: 1 NC / 1NO, 2 NC, 2 NO
- Type: Zb (galvanically isolated changeover contact)
Technical Information:
