608.8153.002
Alt: TI2-SU1Z W
$50.53
Limit Switch, Plunger 1NC/1NO, 240VAC/DC, 10A/2.5AThermoplastic Glass Fibre Reinforced, IP65
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Rated Insulation Voltage: 250 V AC
- Conv. Thermal Current: 10 A AC / 2.5 A DC
- Rated Operational Voltage: 240 V AC; 250 V DC
- Short-Circuit Protective Device: Fuse 6 A gG
- Enclosure: Thermoplastic, glass fiber reinforced (UL 94-V0)
- Contact Type: 1 NC, 1 NO (Zb)
- Connection: 4 screw connections (M3,5)
- Protection Class: II, totally insulated
- Actuator: Plunger (Thermoplastic)
- Optimized size while retaining tried-and-tested connection system
- Two-channel safety monitoring possible
- With captive snap-on cover
- 2 mm contact opening width of slow-action system conforming to EN 81-1 for lift construction
- Mall hysteresis in snap action system
- Actuator can be repositioned by 4 x 90°
