6012811029
Alt: 601.2811.029, SEM2-U1Z
$97.57
Standard Cable Pull Switch
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Series Features Include:
- Die-cast aluminum switch body
- Aluminum plated cover
- Zinc die-cast pull ring
- 2 x M20 x 1.5 cable entries
- Conforms to VDE 0660 T100, DIN EN 60947-1, IEC 60947-1
- Conforms to VDE 0660 T200, DIN EN 60947-5-1, IEC 60947-5-1
- Protection class IP 65 according to IEC/EN 60529
- B10d = up to 2 Mio
- Slow action contact as standard with snap action available on request
- 1NC / 1NO, 2NC / 2NO contacts available (see Downloads for Key)
- Overlapping contacts also available
- Variety of switch body and actuators available to suit most applications
- Rope kits available with 4mm wire cord produced to your application length
