601.2999.097
Alt: 6012999097, SRM-A2Z/U1Z-QF-300-E
$424.41
Rope Pull Switch, 3NC/1NO, Max. Span 246' (75m), Quick-Fix QF, Slack Rope Warning
- Weight:
- 1.07 LBS
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Rated Insulation Voltage: 250 V AC
- Conv. Thermal Current: 10 A
- Rated Operational Voltage: 240 V
- Rated Operational Current: 50 mA
- Short-Circuit Protective Device: Fuse 6 A gG
- Enclosure: Aluminum pressure die-casting
- Cover: Aluminum die-casting
- Actuator: Quick clamping device with integrated turnbuckle (Zn-die cast)
- Cable entry: 3x M20 x 1.5
- Contact Type: 3 NC, 1 NO (Zb) (2 built-in switches S1+S2)
- Connection: 3-pole screw clamp, conductor cross-section ≤ 1,5 mm²
- Protection Class: IP 67 according to IEC/EN 60529
- Up to four positively driven NC contacts
- Separate-action built-in switches
- Max. span length: 75 meters
- Protection class
- Ambient temperature -30°C to +80°C
