Product image is representative only, please verify specifications.
6008104025
Alt: 600.8104.025, C2-U1Z ST
$32.90
Limit Switch, Enclosed, Plastic Body
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Rated Insulation Voltage: 250 VAC
- Conventional Thermal Current: 10 A
- Rated Operational Voltage: 240 V
- Short-Circuit Protective Device: Fuse 6 A gG
- Enclosure: Thermoplastic, glass fiber reinforced (UL 94-V0)
- Actuator: Adjusting screw adjustable, thread M3 with a lock nut
- Contact Type: 1 NC, 1 NO (Zb)
- Assembly: 2 x M3
- Connection: 4 screw connections (M3,5)
- Cable entrance: Rectangle 8,5 x 3,5 mm
- Protection Type: IP20 acc. to EN 60529; DIN VDE 0470 T1, IP30 will be reached when all contacts are connected with outer wire diameter ≥ 2,2 mm
- Small switch body ideal for position monitoring in where space is critical
- Snap on cover for easy access during installation and maintenance
- 2 channel safety monitoring position possible
Technical Information:
