203100
Alt: NBN40-U2-E2
$124.77
Inductive Proximity Sensor, DC, Non-Flush, 10-30VDC, 0-200mA, 40mm Range, PNP NO, IP68/69K, Returns of This Item Must Be Approved by Manufacturer
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Pepperl+Fuchs was founded in 1945 as a small radio workshop in Germany by Walter Pepperl and Ludwig Fuchs. They eventually invented the proximity switch!
Their products include proximity, ultrasonic and photoelectric sensors, explosion protection products, visions systems as well as connectivity and remote I/O options.
The U.S headquarters is located in Twinsburg, Ohio.
Features Include:
- Switching function: Normally open (NO)
- Rated Operating Distance: 40 mm
- Output Type: PNP
- Installation: non-flush
- Assured Operating Distance: 0 - 32.4 mm
- Actual Operating Distance: 36 - 44 mm typ. 40 mm
- Output Polarity: DC
- Operating Voltage: 10 - 30 V DC
- Operating Current: 0 - 200 mA
- Switching Frequency: 0 - 180 Hz
- Connection Type: screw terminals
- Housing Material: PA/metal with epoxy powder coating
- Sensing Face: PA
- Housing Base: Plastic
- Degree of Protection: IP68 / IP69K
Technical Information:
