121208

121208

Alt: MGB-L1-ARA-AM3A1-S6-R-121208

$1,288.96

Multifunctional Gate Box Locking Module, Guard Locking with Guard Lock Monitoring, E-Stop and 2 Illuminated Pushbuttons with Lens Set No. 120344 (6 Pieces, 5 Colors), RC26 Plug Connector, Unicode, Includes Adhesive Labels, Can be Connected

Weight:
2.86 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description

The Euchner CET series is used to guard lock for perseonnel protection in accordance with EN 14119.

This series offers very high guard locking of up to 6500N, 2 safety outputs, a head that can be rotated in 90° steps and it is IP67 rated. The metal housing and safety category 4 and PL e according to EN ISO 13849-1 make this the right safety switch for you!

CET-AP - Single device

  • Safety switch with guard locking and safe guard lock monitoring
  • Integrated CES-AP electronics
  • No special evaluation unit required
  • Safety category 4 and PL e in accordance with EN ISO 13849-1 with any mounting position, head down/up/horizontal
  • Two safe semiconductor outputs and signal output OUT
  • Safety outputs with clocking
  • Input (optional) for connection of feedback loop and start button

CET-AR - For connection of up to 20 AR devices

  • Safety switch with guard locking and safe guard lock monitoring
  • Integrated CES-AR electronics
  • No special evaluation unit required
  • Series connection of up to 20 devices (CES-AR, CET-AR, MGB-AR, ...) in an AR chain possible
  • Safety category 4 and PL e according to EN ISO 13849-1 with any mounting position, head down/top/level
  • Two safe semiconductor outputs and signal output OUT
  • Safety outputs with clocking
  • Input (optional) for connection of feedback loop and start button

CET-AS - For direct connection to AS-Interface

  • ntegrated AS-i connection
  • Robust metal housing
  • Suitable for heavy doors
  • High tamper resistance
  • High protection class IP67
  • Detailed diagnosis with four LEDs (ASi/STATE, 2 colors each)
