ADAM-4562-AE

Features Include:

• Power from the USB port
• Hot swap function supported
• Automatic RS-485 data flow control
• Transmission speed up to 115.2 kbps
• Isolation Voltage: 2,500 VDC
• Connectors: 1 x USB-type A, 1 x DB9 female connector
• Baud Rate (bps): 75 bps~115.2 kbps
• Converter/Repeater: USB to RS-232
• Power Input Unregulated: 12 ~ 24 VDC
• Power Consumption: 3 W @ 24 VDC
• Operation Modes: Support Point-to-Point, Redundant and Ring (half-duplex)
• Optical Power Budget (Attenuation): 15 dB
• Transmission Mode: Single mode (Send and Receive)
• Wavelength: 1310 nm
• Communication Mode: Asynchronous
• Transmission Modes: Full/half duplex, bidirectional

Technical Information:

• Advantech ADAM-4541 / 4542+ / 4561 / 4562 Module Technical Data
• Advantech ADAM-4000 Series User Manual
• Advantech ADAM-4000 Series Access Port Instructions
• Advantech ADAM-4000 Series AIO Calibration Instructions
• Advantech ADAM-4000 Series Reconnection Instructions
• Advantech ADAM-4000 Series DO Voltage/Current Datasheet
• Advantech ADAM-4000 Series Tolerance Range Datasheet
