089953
Alt: 89953, NBB1.5-8GM50-A2-V1, (Was 084953)
$95.59
Inductive Proximity Sensor, DC
- Weight:
- 0.10 LBS
- Minimum Purchase:
- 1 unit
Description
Pepperl+Fuchs was founded in 1945 as a small radio workshop in Germany by Walter Pepperl and Ludwig Fuchs. They eventually invented the proximity switch!
Their products include proximity, ultrasonic and photoelectric sensors, explosion protection products, visions systems as well as connectivity and remote I/O options.
The U.S headquarters is located in Twinsburg, Ohio.
Features Include:
- Switching function: Complementary
- Output type: Two-wire
- Rated operating distance: 1.5 mm
- Installation: flush
- Output polarity: DC
- Assured operating distance: 0 - 1.215 mm
- Output type: 4-wire
- Operating voltage: 10 - 30 V
- Switching frequency: 0 - 1500 Hz
- Connection type: Connector plug M12 x 1 , 4-pin
- Housing material: brass, nickel-plated
- Sensing face: LCP
- Degree of protection: IP67
Technical Information:
