0627038763
Alt: 627038763, BK63H 2P C25A 10kA 240VAC UL1077
$16.50
MCB, UL1077, 2-Pole, C-Curve, 25 Amp, 10kA, 240VAC, Thermal Magnetic Miniature Circuit Breaker
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
LS Electric is a global manufacturer of electrical power distribution equipment that includes circuit breakers and motor starters as well as variable frequency drives and HMIs.
LS Electric America, formerly LG Industrial Systems and LSIS, is a subsidiary of LS Electric headquartered in South Korea.
Specifications
Alternate Part Number
627038763, BK63H 2P C25A 10kA 240VAC UL1077
Amp Rating
25 Amp
Circuit Breaker Type
UL1077
Poles
2 Pole
Series
BK Series
Short Circuit Capacity
10kA
Trip Curve
C Curve
All - Voltage
220/240VAC
Warranty
2-1/2 Years
Weight
1
Features Include:
- Rated Frequency: 50/60 Hz
- Reference Temperature: 40°C
- Trip Type: Thermal Magnetic
- Type of Terminals: Terminal with stirrup(Indirect pressure)
- Tightening Torque: 2Nm (17.5 lbf-in)
- Installation: Mounting on 35mm din rail
